Industrial Pallet Racking
As the largest stockist of racking and shelving in the UK, we are able to work with you on identifying the most suitable pallet racking solution to suit your business needs. Pallet Racking is an adjustable modular storage system used to store pallets that are loaded by forklift trucks.
Phone
08000 147 444
Form
Request a Call Back
Please enter your details below, and click “Send request” to be contacted by a specialist.
Types of Pallet Racking
Wide Aisle Pallet Racking
Adjustable Pallet Racking conforming with British Standard BS EN 15512.
Good quality pallets are stored on pairs of beams. Optional Timber Decking or Wire Mesh Decking provides for storage of varying sized goods.
Narrow Aisle Pallet Racking
High racking and long runs make best use of VNA (Very Narrow Ailse) trucks that don’t need to turn in the aisles.
These trucks require guidance to keep on a straight path. Wire Guidance is supplied with the truck or Mechanical Guide Rail is supplied with the racking.
Heavy Duty Coil Racking
Coil Racks allow for the storage of any material rolled in coils.
This type of pallet racking is fitted with special supports that the coil cradles are mounted onto. The storage solution for coiled materials needs to be extremely heady-duty to ensure the coils can be stored safely without risk of collapse.
Outdoor Racking
Pallet Racking should be Hot-Dip Galvanised for outdoor use. This provides the best level of long-term protection against corrosion.
But it’s not simply about an alternative finish. Outdoor racking systems must be designed to cope with snow and wind loadings on the pallets.
Drive-In Racking
Very dense storage is achieved by placing pallets at the far end of Drive-In lanes, then by working forwards to fill the lanes. This system requires only one loading aisle. A FILO (first-in, last-out) system.
Pallet Flow Live Racking
Pallets are loaded onto inclined beds of rollers and flow from a loading aisle to a picking aisle.
Braked rollers control the rate of descent. Provides high density storage with two aisles creating a FIFO (fist-in, first-out) storage system.
Push-Back Racking
Only one loading aisle provides high density storage but compared with Drive-in, Push-Back Racking reduces forklift travel.
The first pallets to be loaded are pushed back into the racking by the subsequent pallets. A FILO (first-in, last-out) system.
Shuttle Racking
Pallets are placed on powered remote controlled lifting shuttles that take pallets deep into the racking system whilst the forklift trucks are working elsewhere.
A high-density storage system that will bring pallets to the front when required.
Check Out Our Pallet Racking Buyers Guide
Click here
Our services
Pallet Racking Installation & Removal
For any order large or small we offer a full installation service. Our team will manage your project from booking your installation, arranging any hire equipment required, delivering your order, and the installation itself. We make sure everything is completed to the highest safety standards and your product specifications.
Pallet Racking Inspection
If you have a racking system, as an employer, it is your responsibility to ensure your working environment is safe. The Health & Safety Executive (HSE) recommends that British warehouses receive an annual rack inspection from a SEMA (Storage & Equipment Manufacturers’ Association) approved Rack Inspector. Rapid Racking can provide yearly, weekly or reactive inspections.
Rental
If you require storage for a specific length of time then a rental solution may be the perfect option for you. Our rental service is equally viable if you are starting out on a new project or business, allowing you the flexibility to scale up and down with your business without any large upfront costs.
